Ocean Signal, emergency beacon PLB M100X ATEX, AIS & Homing

The Ocean Signal emergency beacon PLB M100X ATEX, AIS & Homing is a professional emergency transmitter for use at sea in explosive areas. The M100X complies with the AIS Class M standard (Regulation: ECC/DEC/(22)02), has an integrated 66-channel GPS receiver and is attached to the lifejacket or sailing jacket (activated automatically when the automatic lifejacket is inflated or alternatively by hand). The alarm is triggered within 15 seconds of activation via AIS and the integrated strobe light. Further details:

• AIS (Automatic Identification System) range approx. 5 nm, display on all AIS devices and chart plotters with AIS function within range of the transmitter
• EPIRB alarm on the homing frequency 121.5 kHz
• Easy integration into the lifejacket due to very compact dimensions
• Automatic activation when installed in the lifejacket (free installation service when purchasing a lifejacket in our Maritimshop)
• At least 12 hours operating time after activation
• Water and pressure-tight up to 10m water depth

Technical data:

• AIS transmission power: 1 watt
• AIS frequencies: 161.975 & 162.025 MHz
• EPIRB homing frequency: 121.5 kHz
• Transmission time: at least 12h
• Operating temperatures: -20°C - +55°C
• Storage temperature: -30°C - +70°C
• Waterproof: up to 10m depth
• Dimensions: approx. 132mm x 53mm x 28mm
• Weight: approx. 92 grams
• Technical standards: ATEX & IECEx Zone 2 (explosive areas) RTCM SC11901, EN303 098-2, EN302 961-2
• Classification: Ex ic T4 Gc

Notes on battery disposal
In connection with the sale of batteries or the delivery of devices containing batteries, we are obliged to inform you of the following: As the end user, you are legally obliged to return used batteries. You can return used batteries, which we carry or have carried as new batteries in our range, free of charge to our dispatch warehouse (dispatch address). The symbols shown on the batteries have the following meaning: The symbol of the crossed-out dustbin means that the battery must not be disposed of with household waste.

Pb = battery contains more than 0.004 per cent lead by mass
Cd = battery contains more than 0.002 per cent cadmium by mass
Hg = Battery contains more than 0.0005 per cent mercury by mass.
